    SPHEROMETER DOUBLE DISC

    SPECTROMETER ADVANCED

    PHY-00678

    Stable Heavy cast-iron base, The main scale (diameter 150 mm ) is divided 0 to 360°and fixed to a table that also holds the telescope. There are two verniers reading up to 1 minute of arc, located 180° apart at opposite sides of the main scale. Both vernier are visible through two protective acrylic windows. Telescope Mounted on a movable pillar, the telescope has a fine adjustment screw, locking screw and axis adjustment. Achromatic objective of focal length 178 mm. Rams den eye-piece 15 X with cross-line graticule. With rack & pinion focusing. Collimator has achromatic objective of focal length 178 mm. Rack & pinion focusing. Adjustable slit, length 6 mm , is made of stainless steel.
    Prism Table Marked with grooved lines to assist positioning of prism in relation to leveling screws. Has interchangeable clamping units for prism and diffraction grating. Packed in wooden case.
    Compare
    Add to wishlist
    Category:

    Enquiry about SPECTROMETER ADVANCED

    Shipping & Delivery

    MAECENAS IACULIS

    Vestibulum curae torquent diam diam commodo parturient penatibus nunc dui adipiscing convallis bulum parturient suspendisse parturient a.Parturient in parturient scelerisque nibh lectus quam a natoque adipiscing a vestibulum hendrerit et pharetra fames nunc natoque dui.

    ADIPISCING CONVALLIS BULUM

    • Vestibulum penatibus nunc dui adipiscing convallis bulum parturient suspendisse.
    • Abitur parturient praesent lectus quam a natoque adipiscing a vestibulum hendre.
    • Diam parturient dictumst parturient scelerisque nibh lectus.

    Scelerisque adipiscing bibendum sem vestibulum et in a a a purus lectus faucibus lobortis tincidunt purus lectus nisl class eros.Condimentum a et ullamcorper dictumst mus et tristique elementum nam inceptos hac parturient scelerisque vestibulum amet elit ut volutpat.

    Related products

    Compare
    Close

    BALANCE SIMPLE SCHOOL

    PHY-00036

    A strong yet sensitive balance made of durable washable plastic with sliding compensators for zero adjustment Capacity 2 Kg.
    Add to wishlist
    Quick view
    Compare
    Close

    AMMETER DUAL SCALE (MOVING COIL)

    PHY-00006

    For d.c. measurement with color coded terminals, meters are housed in a dust proof cases. Provided with zero adjuster. PHY-00005/1          single range - 0-1 Amp, 1.5 Amp, 3 Amp, 5 Amp, 10 Amp.
    Add to wishlist
    Quick view
    Compare
    Close

    BALANCE SPRING METAL TUBULAR

    PHY-00044

    Made of Brass with zero adjustment facility,  scales for clear & easy visibility with suspension loop & hook . Capacity                                  Sub-division Gms                                        Gms. PHY-00044/1          100                                          1 PHY-00044/2          200                                          2 PHY-00044/3          500                                          5 PHY-00044/4          1000                                        10
    Add to wishlist
    Quick view
    Compare
    Close

    BALANCE SPRING TUBULAR ALUMINIUM

    PHY-00047

    Made of aluminum , tubular body,  with zero adjustment facility,  dual scale in metric & newton range, scales for clear & easy visibility with suspension loop & hook . Capacity                  Capacity                  Sub-division Gms                        Newton                   Gms. PHY-00047/1          100                          1                              1 PHY-00047/2          250                          2.5                           5 PHY-00047/3          500                          5                              10 PHY-00047/4          1000                        10                            20 PHY-00047/5          2000                        20                            40 PHY-00047/6          3000                        30                            60 PHY-00047/7          5000                        50                            100
    Add to wishlist
    Quick view
    Compare
    Close

    BALANCE LEVER

    PHY-00032

    Single pan balance for direct reading with dual-range reading 0-250 gm & 1000 gm provided with leveling screw for zero adjustments, metallic frame, all steel parts are chrome plated.
    Add to wishlist
    Quick view
    Compare
    Close

    BALANCE WEIGHTS “PHYSICAL”

    PHY-00054

    Brass, Polished, in a wooden block. PHY-00054/1          Capacity 500 gm Set of Eleven Comprising 1 x 200 gm, 2 x 100 gm, 1 x 50 gm, 1 x 20 gm, 2 x 10 gm, 1 x 5 gm, 2 x 2 gm, 1 x 1 gm.   PHY-00054/2          Capacity 1000 gm Set of Twelve Comprising 1 x 500 gm, 1 x 200 gm, 2 x 100 gm, 1 x 50 gm, 1 x 20 gm, 2 x 10 gm, 1 x 5 gm, 2 x 2 gm, 1 x 1 gm.
    Add to wishlist
    Quick view
    Compare
    Close

    BALANCE SPRING HANGING TYPE

    PHY-00040

    Made from Polystyrene with zero adjustment facility, Large flat scales for clear & easy visibility with hooks. Capacity                                  Sub-division Gms                                        Gms. PHY-00040/1          50                                            1 PHY-00040/2          100                                          1 PHY-00040/3          250                                          5 PHY-00040/4          500                                          5 PHY-00040/5          1000                                        20 PHY-00040/6          2000                                        40
    Add to wishlist
    Quick view
    Compare
    Close

    ARCHIMEDES PRINCIPLE KIT

    PHY-000010

    Consisting metal shape solid regular type and irregular type along with the beaker to collect the displacement liquid, consisting displacement vessel, newton meter & glass beaker.
    Add to wishlist
    Quick view
